Electric Bike Battery
|
 |
Model No: GD-SSDI-E36B |
|
Cell Brand |
Samsung / Sanyo |
|
Cell Code |
ICR18650-22PM / 26F |
|
Chemistry |
Li-ion |
|
Voltage |
36V |
|
Rate |
316.8 Wh/374.4Wh/489.6Wh |
|
Size |
363.66X119.66X73.06 mm |
|
Capacity |
8.8 Ah/10.4Ah / 13.6Ah (Sanyo) |
|
Storage Temp. |
-20～40 ℃ |
|
Configuration |
10S4P |
|
Charge Voltage Limit |
42 V |
|
Continuous Discharge Current |
3 A |
|
Max. discharge cuttent |
10A |
|
Operate Temp. Charge |
0～45 ℃ |
|
Operate Temp. Discharge |
-20～60 ℃ |
|
Cycle Life |
500 Times |
|
PCB Safety Function |
Cell balancing |
|
Over-current protection |
|
Over-discharge |
|
Over-charge |
|
Temperature protection |
|
Secondary protection |
|
 |
Model No: GD-SSDI-E24B |
|
Cell Brand |
Samsung / Sanyo |
|
Cell Code |
ICR18650-22PM / 26F |
|
Chemistry |
Li-ion |
|
Voltage |
25.2V |
|
Rate |
211.2 Wh /249.6 Wh/326.4Wh |
|
Size |
363.66X119.66X73.06 mm |
|
Capacity |
8.8 Ah/10.4Ah/ 13.6Ah (Sanyo) |
|
Storage Temp. |
-20～40 ℃ |
|
Configuration |
7S4P |
|
Charge Voltage Limit |
29.4V |
|
Continuous Discharge Current |
3 A |
|
Max. discharge cuttent |
10A |
|
Operate Temp. Charge |
0～45 ℃ |
|
Operate Temp. Discharge |
-20～60 ℃ |
|
Cycle Life |
500 Times |
|
PCB Safety Function |
Cell balancing |
|
Over-current protection |
|
Over-discharge |
|
Over-charge |
|
Temperature protection |
|
|
Secondary protection |
|
 |
Model No: GD-PAN-E25.2 |
|
Cell Brand |
Samsung |
|
Cell Code |
ICR18650-22PM |
|
Chemistry |
Li-ion |
|
Voltage |
25.2V |
|
Rate |
443.52 Wh |
|
Size |
273.22 x 153.26 x 106.40 mm |
|
Capacity |
17.6 Ah |
|
Storage Temp. |
-20～40 ℃ |
|
Configuration |
7S8P |
|
Charge Voltage Limit |
29.4 V |
|
Continuous Discharge Current |
20 A |
|
Operate Temp. Charge |
0～45 ℃ |
|
Operate Temp. Discharge |
-20～60 ℃ |
|
Cycle Life |
500 Times |
|
 |
Model No: GD-PAN-E36B |
|
Cell Brand |
Samsung |
|
Cell Code |
ICR18650-22PM |
|
Chemistry |
Li-ion |
|
Voltage |
36V |
|
Rate |
396 Wh |
|
Size |
283.91x113.89x104.35 mm |
|
Capacity |
11 Ah |
|
Storage Temp. |
-20～40 ℃ |
|
Configuration |
10S5P |
|
Charge Voltage Limit |
42 V |
|
Continuous Discharge Current |
5 A |
|
Max. discharge cuttent |
11A |
|
 |
Model No: GD-PAN-E25.2A |
|
Cell Brand |
Samsung |
|
Cell Code |
ICR18650-22PM |
|
Chemistry |
Li-ion |
|
Voltage |
25.2V |
|
Rate |
332.64 Wh |
|
Capacity |
13.2 Ah |
|
Weight |
3.425KG |
|
Size |
273.22 x 153.26 x 106.40 mm |
|
Storage Temp. |
-20～40 ℃ |
|
Configuration |
7S6P |
|
Charge Voltage Limit |
29.4 V |
|
Continuous Discharge Current |
20 A |
|
<, SPAN st, yle, ="FONT-FAMILY: Arial; COLOR: black; FONT-SIZE: 9pt" lang=EN-US>Operate Temp. Charge |
0～45 ℃ |
|
Operate Temp. Discharge |
-20～60 ℃ |
|
Cycle Life |
500 Times |
|
PCB Safety Function |
Cell balancing |
|
Over-current protection |
|
Over-discharge |
|
Over-charge |
|
Temperature protection |
|
Secondary protectio |
|
|
|
